Refractory Hercynite Fire Brick for Burning Zone of Rotory Kiln

MAGNESIA HERCYNITE BRICKare made of top grade of sintered magnesia, High-purity sintered iron alumina spinel , with our unique and advance particle grading . pressing by auto pressing machine and and firing under higher temperature in the tunnel kiln .

Quantity:
  • YUFENGREC ® MHB85
  • YUFENGREC®

YUFENGREC®MAGNESIA HERCYNITE BRICK   are made of top grade of sintered magnesia, High-purity sintered iron alumina spinel  , with our unique and advance particle grading . pressing by auto pressing machine and  and firing under higher temperature in the  tunnel kiln .


APPLICATION

* Central Burning Zone of Rotary Kiln


KEY FEATURES

*  Quick  Coating Forming

*  Stable Coating,no peal-off when stop kiln

*  Excellent resistance to chemical attack

*  Low Thermal Conductivity

*  Good Energy saving


TECHNICAL DATA

Item

Unit

YUFENG-MHB85

MgO

%

≥85

Fe2O3

%

≥4

Al2O3

%

≥4

Bulk Density   g/cm3

≥2.90

Cold Crushing Strength    MPa

≥50


Refractoriness Under Load under 0.2 MPa

℃

≥1650

Thermal Conductivity at 700℃

w/m.k

3.5

Thermal Shock Resistance  air cooling at 950 ℃

cycle

≥95

The data are average results of tests under standard procedures and are subject to variation. Results should not be used for specification purposes or creating any contractual obligation. For more information on the safety applications or materials ,please refer to the work practices and material safety data sheet
